Mesh 10 0.9mm Stainless Steel Diamond Mesh 304ss Expanded Diamond Mesh
| Place of Origin | CHINA |
|---|---|
| Brand Name | LONGKUO METAL WIRE MESH |
| Minimum Order Quantity | 1rolls |
| Price | $6 ~ 99/roll |
| Packaging Details | Plastic bag, Moistureproof paper and Wooden pallet |
| Delivery Time | About 7 work days depends on the supply |
| Payment Terms | T/T, Western Union |
| Supply Ability | 100,000m2/year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Stainless Steel Diamond Mesh | Mesh Count | 10 Mesh |
|---|---|---|---|
| Material | SS 201/304/316/304L/316L | Diameter Range | 0.9mm/1mm |
| Colors | Body/black/white/Colorful/Customizable | Hole Shape | Square Hole |
| Market | Europe, America, Australia, Asia, Afirca Etc | Type | Weave Wire Mesh |
| Advantage | Superior Wire,standard Mesh | Sample | According To Size |
| High Light | 0.9mm Stainless Steel Diamond Mesh,Mesh 10 Stainless Steel Diamond Mesh,304ss expanded diamond mesh |
||
Product Description
Mesh 10 Wire Diameter 0.9mm Customizable Stainless Steel Diamond Mesh
Stainless Steel Diamond Mesh Product Description
Our factory is a chemical factory integrating production, sales, wholesale and retail. All products are provided with one-stop service. From wire drawing, mesh weaving, deep processing and inspection, we operate independently. All materials, sizes and specifications can be customized according to customer requirements. It is one of the largest manufacturers of stainless steel wire mesh in China. We have a large stock of many popular standard items.
Stainless Steel Diamond Mesh Specifications
Materials: 304/304L stainless steel, 316/316L stainless steel, 201 stainless steel
Color: black, gray, white, yellow, silver, metal primary color and other colors
Specification and size:
11 mesh * 0.8mm, 12 mesh * 0.7mm, 14 mesh * 0.6mm, 14 mesh 0.55mm, 14 mesh 0.5mm. Mesh size: 1500mm * 3000mm; 1300mm * 2600mm; 1200mm * 2000mm; 1200mm * 2400mm; 1000 * 2400mm; 900mm * 2000mm; 900mm * 2400mm; 750mm * 2000mm; 750mm * 2400mm.
Stainless Steel Diamond Mesh Parameter table
| MESH | WIRE DIAMETER(mm) |
| 10 | 1mm / 0.9mm |
| 11 | 0.9mm / 0.8mm |
| 12 | 0.8mm / 0.7mm |
| 13 | 0.6mm |
| 14 | 0.50mm / 0.55mm / 0.60mm |
Stainless Steel Diamond Mesh Technical Parameters
| AISI Material |
Chemical omposition(%) | |||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Cu | Ti | |
| 201 | ≤0.15 | ≤0.75 | 5.5~7.5 | ≤0.06 | ≤0.03 | 3.5~5.5 | 16~18 | - | - | |
| 304 | <0.08 | <1.0 | <2.0 | <0.035 | <0.03 | 8~10 | 17~19 | - | - | - |
| 304L | <0.03 | <1.0 | <2.0 | <0.04 | <0.03 | 9~13 | 18~20 | - | - | - |
| 316 | <0.08 | <1.0 | <2.0 | <0.04 | <0.03 | 10~14 | 16~18 | 2.0~3.0 | - | - |
| 316L | <0.03 | <1.0 | <2.0 | <0.04 | <0.03 | 12~15 | 16~18 | 2.0~3.0 | - | |
Stainless Steel Diamond Mesh Service
Our company has a large number of regular specifications of stock, according to customer requirements for production and processing and customization.
