2mm Stainless Steel Screen Mesh 500 Twill Weave Mesh 1.2m

Place of Origin CHINA
Brand Name LONGKUO METAL WIRE MESH
Minimum Order Quantity 10rolls
Price $66/roll ~ $500/roll
Packaging Details plastic bag, Moistureproof paper and wooden pallet
Delivery Time 5-15 work days
Payment Terms T/T, Western Union
Supply Ability 100,000m2/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Stainless Steel Screen Mesh Mesh Opening 0.025-23.37mm
Material Stainless Steel 201, 304, 304L, 316, 316L Wire Diameter 2 - 0.018mm
Length Of Roll 30m/roll 50m/roll Or As Required Color Customized
Width Of Roll Usually 1m, 1.2m Or Others Usage Filter, Screen Prinitng, Printing And Dyeing
Sample Small Sample Free We Are Factory Low MOQ, Lowest Price And The Best Service
Feature Heat Resistance, High Tension
High Light

Stainless Steel Screen Mesh longkuo

,

500 Mesh Twill Weave Mesh longkuo

,

twill weave mesh 1.2m longkuo

Leave a Message
Product Description

Screen Printing Industry 500 Mesh Twill Weave type Stainless Steel Screen Mesh





Technology



1. Plain weave:

Plain weave is a knitting method in which each warp crosses each weft, the diameter of which is the same as weft, and the warp and weft form a 90 degree angle. Plain woven mesh is square and uniform in size. Each warp is crossed up and down each weft, the diameter of the warp is the same as the weft, and the warp and weft form a 90 degree angle.

2. Twill weave:

The knitting mode in which each warp thread crosses each two weft threads and each weft thread crosses each two diameter threads.

3. Dense weave:

Warp and weft yarns have different diameters and mesh numbers. They are characterized by thin warp and dense weft, thick warp and thin weft. The direction of length is warp and the direction of width is weft. Dense mesh is divided into plain weave and twill weave.

4. Mat net twill knitting:

The knitting mode in which each diameter filament crosses up and down every two weft yarns, and each weft filament crosses up and down every two diameter yarns.

5. Double wire Dutch knitting:

This kind of knitting is very similar to twill Dutch knitting. There are two weft threads, which can be closely overlapped with the warp. This kind of silk cloth is mostly used for micron level filtration.



Advantage



1. Good acid, alkali and corrosion resistance;

2. High strength, strong tensile force, toughness and wear resistance, durable;

3. It is resistant to high temperature oxidation, and the nominal temperature of 304 stainless steel screen is 800 ℃;

4. Normal temperature processing, that is, easy plastic processing, makes the possibility of using stainless steel screen diversified;

5. High finish, no surface treatment, easy maintenance.



Characteristics



1. Precise structure, uniform mesh, good filtration accuracy, good corrosion resistance and durability.

2. It has the properties of acid resistance, alkali resistance, temperature resistance, tensile and wear resistance.

3. High finish, no surface treatment, easy maintenance.



Packaging



Before exporting, our products will be manually packaged with plastic bag, Moistureproof paper and tailor-made wooden boxes, in order to prevent damage.



Material composition table



AISI
Material
Chemical omposition(%)
  C Si Mn P S Ni Cr Mo Cu Ti
201 ≤0.15 ≤0.75 5.5~7.5 ≤0.06 ≤0.03 3.5~5.5 16~18 - -
304 <0.08 <1.0 <2.0 <0.035 <0.03 8~10 17~19 - - -
304L <0.03 <1.0 <2.0 <0.04 <0.03 9~13 18~20 - - -
316 <0.08 <1.0 <2.0 <0.04 <0.03 10~14 16~18 2.0~3.0 - -
316L <0.03 <1.0 <2.0 <0.04 <0.03 12~15 16~18 2.0~3.0 -
